Multicycle
The monitor used as part of the B&R Multiplex System is user-friendly with touch screen capability.
Let's say you want to change the multicycle settings of the packer. All you have to do is tap the screen
to select Shortcut Button #3 "Automated Features" (see Figure 3-22). Once the corresponding page
is loaded, you are presented with 3 options: 1- OFF (1 cycle); 2- 2 cycles; 3- 3 cycles. Choose the
desired number of cycles by tapping on the corresponding radio button.
N : When a specific page is loaded on the monitor display screen, the corresponding button in the
OTE
Quick Access Toolbar becomes black.
Figure 3-22 Multicycle page
N : The packer multicycle function has been preset at the factory to carry out three cycles.
OTE
When the
MULTICYCLE
move according to the default number of cycles (that is 3) or to the number of cycles you chose.
Figure 3-23 Control panel
Part # 200277 (rev.00.10.2024)
switch on the control panel is on and the packer is activated, the packer will
Start cycle button
Pump switch
Multicycle switch
Controls and Indicators 65
