68 Controls and Indicators
The ENABLE/DISABLE button is used to force a particular function to be active or inactive.
N : If both FORCE ENABLE/DISABLE and ON/OFF buttons are orange-lighted, this means the
OTE
user is logged in to the system.
Figure 3-26 Cabine I/O Module Page (user logged in)
If the user clicks on a particular function in the list, a new page opens up showing the status of several
I/Os to help with troubleshooting (see Figure 3-27).
Figure 3-27 List of I/Os (blue = inactive, green = active)
N : To go from one module to another, tap on Previous as many times as needed to reach the I/O
OTE
Status Page (see Figure 3-24), then select the module you want to access.
