Figure A-6 Dual ICC bumper
Unloading the Left-Hand Side Compartment of the Body
To unload the left-hand side compartment of the body (with full ICC bumper on the left-hand side
tailgate):
1. Apply the parking brake, then exit the cab.
2. Remove the left-hand side tailgate safety pin, then go back in the cab.
3. On the control panel, press the L
A-7).
Figure A-7 Tailgate selector switch
4. Open the tailgate completely by pressing and holding down the T
cab control panel (see Figure A-8).
Part # 200277 (rev.00.10.2024)
-H S T
EFT AND IDE AILGATE
L
EFT
TAILGATE ACTIVATION
R
IGHT
TAILGATE ACTIVATION
Operating a Commingled Unit 125
A switch (see Figure
CTIVATION
-
HAND SIDE
switch
-
HAND SIDE
switch
U switch on the in-
AILGATE P
