100 Operating the A
UTOMIZER
Loading Procedure
Warning!
Improper use of the truck, including the packer and the lifting arm, can result in serious
injury.
To load refuse into the hopper:
1.
Bring the truck to the roller cart to be dumped.
2.
Slow down when near the cart.
3.
Align the lifting arm with the roller cart that you intend to pick up.
4.
With the arm parked alongside the truck, use the joystick to reach the cart.
Extension of the arm may be needed to reach the cart.
N : See Figure 3-43 for proper operation of the lifting arm with the joystick.
OTE
If need be, close the grabber just enough to avoid slamming on adjacent carts. To do so, apply
short presses on the C
The operator must push on the deadman switch in order to enable joystick functions (see Figure
I :
MPORTANT
4-8).
Figure 4-8 Joystick
Close grabber button
Open grabber button
Warning!
Part # 200277 (rev.00.10.2024)
G
LOSE RABBER
Never by-pass the deadman switch with tape, tie-wrap, or anything else in order to
operate the arm.
button (see Figure 4-8).
Deadman switch
