Labrie AUTOMIZER Helping Hand Operator's Manual page 118

106 Operating the A
UTOMIZER
Unloading Procedure (Vehicles w/ Full-Eject Body)
: For vehicles with tip-to-dump body, go to page 102.
N
OTE
Unloading packed refuse carried in an A
the packer. The unloading process is an easy one thanks to the multiplex system, which is installed in
all A
UTOMIZER
automatically, that is the opening of the tailgate and the ejection of refuse from the storage body.
Retracting the packer and closing the tailgate must be done manually.
Once you have completed your collection route, fully raise the crusher panel (if installed), and park
the automated arm alongside the hopper.
Warning!
The following is the standard unloading procedure:
1. Drive the vehicle to the landfill.
2. Ensure the vehicle is on safe, stable and level ground.
3. Check the overhead clearance before opening the tailgate.
4. Remove the tailgate safety pins (see Figure 4-11).
Figure 4-11 Safety pin
5.
On the control panel, press and hold the A
This switch must be kept down for the unloading process to continue. Releasing it will stop the
process immediately no matter what function was active.
As soon as you press this switch, the tailgate will open. Then, once the tailgate is completely open,
forming a 90
strokes before the complete and final stroke. This is done this way to prevent waste or refuse from
piling up on the follower panels, which would ultimately fall behind the packer. The number of
short strokes made by the packer during the unloading process is set at the factory.
Part # 200277 (rev.00.10.2024)
units. With just the use of a switch, the first steps of the unloading process can be done
Ensure the overhead is clear before opening the tailgate.
o
angle with the body, the packer will start moving. It will perform several short
unit with the full-eject feature requires the use of
UTOMIZER
-E switch (see Figure 3-35).
UTO JECT
