76 Controls and Indicators
T U Switch
AILGATE P
This control switch (see Figure 3-32) is used to raise the tailgate. Press and keep down this switch to
raise the tailgate to the desired height.
Before using this switch, make sure that the truck is parked on safe level ground.
I :
MPORTANT
Remove both tailgate-locking pins before using this control switch.
I :
MPORTANT
Warning!
Do not drive the vehicle when the tailgate is not fully closed.
N : When the tailgate is unlocked both the in-cab buzzer (see Figure 3-37) and the backup alarm
OTE
will start sounding off. A red warning light, located on the buzzer, will also blink.
N : Each time the tailgate is unlocked, the message "Tailgate Unlocked" appears on the monitor
OTE
display.
Figure 3-37 Buzzer w/ red warning light
N : If the upward movement of the tailgate is stopped at any position except the fully open
OTE
position, both T
N : When the tailgate reaches the fully open position, the T
OTE
the T
AILGATE
on tip-to-dump units).
Part # 200277 (rev.00.10.2024)
U and T
AILGATE P AILGATE
D switch will turn blue (standard feature on full-eject units; optional feature
OWN
Red warning
light
D switches will flash red.
OWN
U
AILGATE P
switch will turn green while
