102 Operating the A
UTOMIZER
Unloading
The process of unloading the body depends on the type of A
a tip-to-dump body or with a full-eject body. The two versions of this process are explained below.
Unloading Procedure (Vehicles w/ Tip-to-Dump Body)
: For vehicles with a full-eject body, go to page 106.
N
OTE
Once you have completed your collection route, make sure the automated arm is fully retracted
alongside the truck and the crusher panel (if installed) is lowered. Keep some garbage not packed in
front of the packer in order to facilitate the unloading process.
Warning!
The following is the standard unloading procedure:
1.
Drive the vehicle to the landfill.
2.
Ensure the vehicle is on safe, stable and level ground.
3.
Check the overhead clearance before opening the tailgate and raising the body.
4.
Remove both tailgate safety pins.
Figure 4-9 Safety pin
5. Open the tailgate completely by pressing and holding down the T
cab control panel (see Figure 3-32).
6.
Once the tailgate is completely open, raise the body by pressing and holding down the B
switch on the in-cab control panel (see Figure 3-32).
Part # 200277 (rev.00.10.2024)
Ensure the overhead is clear before raising the body.
vehicle you have, either with
UTOMIZER
U switch on the in-
AILGATE P
U
ODY P
