Labrie AUTOMIZER Helping Hand Operator's Manual page 51

Changing to Right-Hand Side Driving Position
The following procedure applies ONLY to cabs that had been modified by Labrie Environmental
Group. It must be followed at the beginning, but also at the end of the collection route in order to
revert to the left-hand side driving position.
: This procedure applies only to vehicles that had been modified by Labrie Environmental
N
OTE
Group and that are equipped with dual driving position. Some units are designed only with a
single driving position.
If the cab has been modified by the chassis manufacturer, the operator MUST ignore the following
procedure and rather follow the chassis manufacturer's recommendations.
Before using the right-hand side driving position, do the following:
1.
Drive the vehicle to the beginning of the collection route using the left-hand side steering wheel.
2.
Stop the vehicle and apply the parking brake.
3.
Press the emergency stop button on the packer control station (see Figure 3-39).
4.
Turn OFF the engine.
5.
Move to the right-hand side driving position.
6.
Shift the driving position switch to the right (see Figure 2-28).
All the electrical accessories of the right-hand side driving position are then enabled.
Figure 2-28 Driving position switch (optional)
7.
Enable the right-hand side joystick by moving the joystick selector switch to the right (if
installed).
On some trucks, selecting the appropriate joystick is done using the joystick selector switch
located on the control panel (see Figure 2-29).
• Press the top part of the switch to enable the right-hand side joystick.
• Press the bottom part of the switch to enable the left-hand side joystick.
A blue-lighted switch means the corresponding function is disabled.
A green-lighted switch means the corresponding function is enabled.
Part # 200277 (rev.00.10.2024)
Safety 39
