Figure 1-8 Arm joystick
N : The full-eject version of the A
OTE
uses a 3-stage, double-acting telescopic cylinder (Figure 1-6) to horizontally eject the load out
of the rear opening.
Multiplex System
The A
UTOMIZER
The Multiplex System used by Labrie Environmental Group is a CAN-based system that integrates a
monitor, a control panel and a number of electronic modules. This whole system has been designed
to help you operate your unit in an efficient and easy way.
There are two versions of the multiplex system used by Labrie Environmental Group, one is
manufactured by IFM, the other by B&R. Your truck is equipped with one of them. Either version
works the same way to control and monitor the operation of the various equipment or devices that
are onboard your vehicle. See IFM Multiplex System on page 41 for more details.
A
I :
UTOMIZER
MPORTANT
Key Features of the A
The A
UTOMIZER
 Central grease point for follower panel rollers (standard)
 Grease zerks and central grease point for packer cylinder pin (standard)
 Hardox liners on floor and sides (optional)
 12-foot arm extension
 Arm lifting capacity at full extension: 1000 lb
 Reinforced body walls
 Tapered body
 Oversized clean-out doors on both sides of the truck
Part # 200277 (rev.00.10.2024)
UTOMIZER
is equipped with an electronic monitoring system called the Multiplex System.
units must be operated by only one person.
UTOMIZER
comes with a series of key features, such as:
is not a tip-to-dump type of refuse truck. Instead, it
Introduction 5
