56 Controls and Indicators
J1939
The J1939 page is useful when you need some specific information (e.g. current gear, road speed,
brake status).
Figure 3-16 J1939 page
Your vehicle is equipped with 2 different CAN-based communication buses:
 the J1939 bus, which is used for the chassis equipment; and
 the CANopen bus, which is used for the body.
These 2 communication buses are completely independent of one another, except for some specific
data that are transferred from the chassis J1939 bus to the IFM Multiplex System, where they are
used. These specific data are the following:
 selected gear
 current gear
 road speed
 engine rpm
 brake
 parking brake
Press "Esc" to return to the preceding page.
