Control Panel
The control panel is located at the center of the cab for easy access during collection and operation.
On a truck with two driving positions, this control panel is mounted on a pivotal support which can
be turned by hand.
The following is a description of all control switches and indicators mounted on this panel.
Figure 3-32 Control panel (part 1)
Figure 3-33 Control panel (part 2)
Figure 3-34 Control panel (part 3) - Optional indicator
Part # 200277 (rev.00.10.2024)
Hydraulic Strobe Crusher
pump light
Packer
Hopper Crusher
multicycle work light
Hydraulic
alarm
Tailgate
Body
up
up
up
Body Tailgate
down
down
down
Controls and Indicators 73
Inhibit
10 sec.
Auto-
packing
