98 Operating the A
UTOMIZER
Warning!
Always apply the lockout/tagout procedure before entering the hopper area. See Locking
Out and Tagging Out the Vehicle on page 33.
Loading Refuse
Before undertaking the loading process with your A
I :
MPORTANT
provided with the proper training related to the safe operation of the vehicle. As an operator, you
must be familiar with the location, operation and function of all controls and warning indicators
provided and adhere to all safety rules and procedures.
Using the arm to load the hopper, fill up the garbage as high as the packer and then press the green
button to get a complete cycle. Be careful of explosive projectile objects and watch for overspills. See
"Pack on the Go" on page 101.
While collecting roller carts, you should start the packer cycle every time a cart has been emptied into
the hopper. See Loading Procedure on page 100.
Packer Description
N : This section applies to all A
OTE
The packer, made of high strength steel, travels the hopper to push refuse into the body. If any piece
of garbage exceeds above the packer, it will be crushed or bent against the rear breaker bar, located
just above the opening of the body.
Figure 4-6 Breaker bar
Whatever piece of garbage that is not pushed inside the body on a given stroke of the packer will fall
back in the hopper when the packer retracts. As another cycle is activated by the operator, what was
left in the hopper in the previous stroke of the packer will be pushed into the body.
Part # 200277 (rev.00.10.2024)
UTOMIZER
vehicles except the Pendulum.
UTOMIZER
unit, ensure that you have been
