Cabine I/O Module Page
After you tap on the Cabine I/O button, the Cabine I/O Module Page opens up (see Figure 3-25).
Figure 3-25 Cabine I/O Module Page
N : When a specific page is loaded on the monitor display screen, the corresponding button in the
OTE
Quick Access Toolbar becomes black.
This module allows the operator to force a function to be overridden, that is, to make an inactive
function active and an active function inactive.
First thing first, tap on the FORCE ENABLE button to display all the functions of the Cabine I/O
Module Page.
The Cabine I/O Module Page contains a list of functions, an indicator light and 2 buttons (FORCE
ENABLE/DISABLE and ON/OFF). Each element in the list represents a particular function of the
truck and is preceded by an "I" for input or by an "O" for output. For example, "i_ServiceBrakePssr"
relates to the input element coming from the service brake pressure switch and "o_ServiceBrakePssr"
relates to the output element coming from the service brake pressure switch. When a particular
function is selected in the list, it becomes blue. The light indicator in the middle of the screen will tell
you if that function is active or not. If the function is active, you can force it to be inactive by tapping
on the DISABLE button. Alternatively, if the function is inactive, you can force it to be active by
tapping on the ENABLE button.
N : The I/O Module Page list of functions is read-only if the user is not logged in or does not have
OTE
the required access rights.
The light indicator can be red-lighted or green-lighted. It is red-lighted when the selected function in
the list is not active; it is green-lighted when that function is active.
