Labrie AUTOMIZER Helping Hand Operator's Manual page 93

Both tailgate safety pins must be put back in locking position once the tailgate is closed.
I :
MPORTANT
In-Cab Packer Control Station
The A
UTOMIZER
features three large push-buttons, each having its own color (red, green and yellow).
The operator can use these buttons to extend or retract the packer or to immediately stop the packer
extension/retraction when needed.
The following is a short description of those three push-buttons:
Stop Push-Button (red)
The E
MERGENCY
up/down, tailgate up/down, packing, etc.). Pressing the red button will make the packer and the
automated arm stop where they are. The red button has to be manually pulled out and the P
switch pressed again to reactivate the hydraulic system.
Figure 3-39 Stop push-button
Pack Push-Button (green)
The P
ACKER
complete cycle takes about 20 seconds at idle.
Figure 3-40 Pack push-button
Part # 200277 (rev.00.10.2024)
has a packer control station located on the in-cab control panel. This control station
S button (see Figure 3-39) will stop all hydraulic functions on the truck (body
TOP
S C button (see Figure 3-40) activates the packer for one complete cycle. A
TART YCLE
Controls and Indicators 81
UMP
