122 Operating a Commingled Unit
Loading Procedure
Caution!
When using the lifting arm, double-check mirrors and surroundings for extra safety. Always
ensure total clearance around the vehicle.
To load refuse into the hopper:
1. Align the lifting arm on the vehicle with the roller cart that you intend to pick up.
N : To perform any action or movement of the lifting arm, remember to always press and hold the
OTE
deadman switch (see Figure 3-42).
2.
Place the chute in the proper position by using the appropriate chute control button on the top of
the joystick (see Figure A-4, left).
3. Extend the lifting arm to reach the roller cart, closing the grabber just enough to avoid slamming
on adjacent carts.
4.
Grab the roller cart with the grabber and raise it about two feet from the ground.
5.
Fully retract the lifting arm and raise it until the cart tips into the hopper, emptying its content.
6.
Lower back the cart to about two feet above the ground.
7. Extend and lower the lifting arm to place the cart back to where it was.
8. Open the grabber to release the cart.
9. Fully retract the arm and park the grabber open alongside the vehicle (for door-to-door waste
collection only).
Danger!
Never drive the A
popping out.
N : For proper operation of the lifting arm with the joystick, see Figure 3-43.
OTE
Part # 200277 (rev.00.10.2024)
with the lifting arm extended and/or the grabber closed and
UTOMIZER
