Inspecting Right-Hand Side Driving Controls
: This section applies only to cabs modified by Labrie Environmental Group. If your cab has not
N
OTE
been modified by Labrie Environmental Group, please refer to your cab manufacturer's
recommendations.
Enter the right-hand side cab extension and operate the corresponding driving controls. Report any
defective system to the maintenance personnel.
To inspect the right-hand side driving controls:
1.
Turn the steering wheel to the left then to the right as you slowly move the vehicle forward.
2.
Stop the vehicle by applying the foot brake.
3.
Engage the parking brake and try to get the vehicle moving by throttling up with the right-hand
side accelerator pedal.
4. Throttle down to idle, step on the foot brake and disengage the parking brake.
5. Apply the temporary handbrake (if equipped) and try to get the vehicle moving by throttling up
with the right-hand side accelerator pedal.
6.
Apply the parking brake.
You must follow the inspection sheet provided by your employer. If your employer does not have any,
ask his permission to use the Inspection Sheet on page 96.
Adjusting Mirrors
Every time you use the A
around visibility from either driving position.
The following diagrams show the ideal mirror adjustments for both driving positions.
Figure 4-3 Mirror adjustment from left and right driving positions
Part # 200277 (rev.00.10.2024)
, you must adjust the mirrors to make sure that you have all-
UTOMIZER
93
