Labrie AUTOMIZER Helping Hand Operator's Manual page 33

Figure 2-7 Service hoist joystick
5. Release the safety prop by using the safety prop handle (see Figure 2-8).
6.
Fully tilt the prop towards the right.
Figure 2-8 Prop latch
7.
Lower the body until it rests on the safety prop.
The body can be lowered by pulling back the hoist joystick (see Figure 2-7) and holding it until
the body reaches the desired height.
8.
Lock out and tag out the vehicle (see Locking Out and Tagging Out the Vehicle on page 33).
You can now work safely underneath the body.
Putting the Service Hoist Safety Prop Back in Place
To put the service hoist safety prop back in place:
1. Make sure that there is enough clearance above the body to raise it safely and that the truck is on
safe level ground.
2.
Raise the body until the safety prop can move freely.
The body can be raised by pushing the hoist joystick forward (see Figure 2-7) and holding it until
the body reaches the desired height.
3.
Put the safety prop back in its place. Use its latch to secure it (see Figure 2-8).
Part # 200277 (rev.00.10.2024)
Safety 21
