7.7 PERFORMING THE LIVE ANALYSIS

In the middle of observation or searching for the field of view, the operator can check the EDS analysis result
of the view currently being observed.
The spectra in the spectrum monitor cannot be saved. Perform the EDS analysis to save a spectrum.
1.
Click the Observation icon.
2.
The EDS analysis result of the area being observed on the spectrum monitor appears.
The spectrum shape can be checked on the spectrum monitor while the contained elements are shown
at the bottom left of the GUI.
3.
The EDS analysis result of the area being observed on the spectrum monitor appears.
When the stage movement is stopped, the live analysis resumes.
7-10
No.ISMIT200-1E
