JEOL JSM-IT200 Instructions Manual page 154

5.9.4 Switching the magnification
1.
Click △ mark under magnification of the Photo data.
In the below figure, click the △ mark under『×5』, and Magnification window is displayed.
2.
Set the magnification.
Click the preset button or use the slide button for setting.
The value set by using the slide button is displayed in the upper middle of the slide bar.
Changing the preset button
Drag the value selected by using the slide button (upper middle of the slide bar) and drop it on the
preset button desired to change. The value of the preset button changes.
No.ISMIT200-1E
Selected value
Slide button
Preset buttons
5-25
