5.1 UI OPERATION
Two operation modes for the user interface (UI) are available for operating the icon selection, moving the
field of view and the Tools.
Touch mode (touch operation by a finger or a touch pen)
Mouse mode (operation by the mouse)
5.1.1 Touch mode
Operation
Click
Double-Click
Press and Click
Touch and hold
Swipe
Flick
Drag
Pinch out
Pinch in
Rotate
1
To change the operation mode, select Settings in the menu bar, then SETTINGS window－Operation (Touch or Mouse).
No.ISMIT200-1E
1
Center
Action
Click the screen once with a fingertip (select).
Click the screen twice with a finger tip (execute).
Press the screen with one finger and Click with another
finger quickly.
※Same action as mouse right-click
Continue to press the screen.
※Same action as mouse right-click
Slide the fingertip while pressing the screen.
Slide your finger across the screen quickly.
Press with a finger while sliding it on the screen.
Press the screen with 2 fingers and move them
outward with a pinching motion.
magnification
Press the screen with 2 fingers and move them
inward with a pinching motion.
magnification
Press the image with 2 fingers and move one
finger in an arc, while keeping the other finger fixed
at the center of rotation.
An image can be rotated to the right or left by
sliding the moving finger either clockwise or
counterclockwise.
Example）Up
Example）Down
