RGB_OUT , IO, Address 0x02[1]
A control to select output color space and the correct digital blank level and offsets on the RGB or YPrPb outputs. It is used in
conjunction with the INP_COLOR_SPACE[3:0] and ALT_GAMMA bits to select the applied CSC.
Function
RGB_OUT Description
0 (default) YPbPr color space output
1 RGB color space output
ALT_GAMMA , IO, Address 0x02[3]
A control to set the colorspace of the input video. To be used in conjunction with ALT_GAMMA and RGB_OUT to configure the color
space converter. A value of 4'b1111 selects automatic setting of the input color space base on the primary mode and video standard
settings. Setting 1000 to Setting 1110 are undefined.
Function
ALT_GAMMA Description
0 (default) No conversion
1 YUV601 to YUV709 conversion applied if input is YUV601. YUV709 to YUV601 conversion applied if input is YUV709
Table 36. Automatic CSC Selection
INP_COLOR_SPACE[3:0] (Input Color Space)
00 = RGB
01 = (YCbCr /YUV 601)
10 = (YCbCr /YUV 709)
CSC_COEFF_SEL_RB[3:0] , Addr 44 (CP), Address 0xF4[7:4] (Read Only)
Readback of the CP CSC conversion when configured in automatic mode.
Function
CSC_COEFF_SEL_RB[3:0]
0000 (default)
0001
0011
0101
0111
1001
1010
1111
xxxx
Table 37. CSC Configuration for All CSC Modes Reported by CSC_COEFF_SEL_RB
CSC_
CSC SCALE
[1:0]
Mode A1
0b0000 CSC in bypass mode. In this mode the CSC effectively performs a color conversion based on the CSC coefficients set in registers CSC_SCALE, A1,
0b0001 0b01 0x0800
0b0011 0b01 0x0800
0b0101 0b00 0x0964
0b0111 0b00 0x0B71
0b1001 0b01 0x0800
0b1010 0b01 0x0800
A2 A3 A4
A2, A3, A4, B1, B2, B3, B4, C1, C2, C3, and C4.
0x1A6A 0x1D50 0x0423
0x1C54 0x1E89 0x0291
0x04C9 0x01D3 0x0000
0x0368 0x0127 0x0000
0x0188 0x00CB 0x1ED7
0x1E56 0x1F14 0x014A
RGB_OUT
ALT_GAMMA = 0
0 YCbCr 601
1 RGB
0 YCbCr 601
1 RGB
0 YCbCr 709
1 RGB
Description
CSC is bypassed
YPbPr 601 to RGB
YPbPr 709 to RGB
RGB to YPbPr 601
RGB to YPbPr 709
YPbPr 709 to YPbPr 601
YPbPr 601 to YPbPr 709
CSC in manual mode
Reserved
B1 B2 B3
0x0800 0x0AF8 0x0000
0x0800 0x0C52 0x0000
0x1927 0x082D 0x1EAC
0x1893 0x082D 0x1F3F
0x0000 0x07DE 0x1F6C
0x0000 0x0834 0x009A
Rev. A | Page 94 of 184
Hardware User Guide
CSC Mode Used (Output)
ALT_GAMMA = 1
YCbCr 709
RGB
YCbCr 709
RGB
YCbCr 601
RGB
B4 C1 C2
0x1A84 0x0800 0x0000
0x19D7 0x0800 0x0000
0x0800 0x1A93 0x1D3F
0x0800 0x19B2 0x1E21
0x005B 0x0000 0x1F1D
0x1F9A 0x0000 0x00EB
C3 C4
0x0DDB 0x1912
0x0E87 0x18BC
0x082D 0x0800
0x082D 0x0800
0x07EB 0x007B
0x0826 0x1F78
