Analog Devices Advantiv ADV7611 Hardware User's Manual page 169

Hardware User Guide
NEW_AUDIO_INFO_ST, IO, Address 0x7A[1] (Read Only)
Latched status for the new audio InfoFrame interrupt. Once set, this bit will remain high until the interrupt is cleared via
NEW_AUDIO_INFO_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
NEW_AUDIO_INFO_ST
0 (default)
1
NEW_AVI_INFO_ST, IO, Address 0x7A[0] (Read Only)
HDMI Edg INT Status 2 register consists of fields: FIFO_NEAR_OVFL_ST, FIFO_UNDERFLO_ST, FIFO_OVERFLO_ST,
CTS_PASS_THRSH_ST, CHANGE_N_ST, PACKET_ERROR_ST, AUDIO_PCKT_ERR_ST, and NEW_GAMUT_MDATA_ST.
FIFO_NEAR_OVFL_ST, IO, Address 0x7F[7] (Read Only)
Latched status for the audio FIFO near overflow interrupt. Once set, this bit will remain high until the interrupt is cleared via
FIFO_OVFL_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
FIFO_NEAR_OVFL_ST
0 (default)
1
FIFO_UNDERFLO_ST, IO, Address 0x7F[6] (Read Only)
Latched status for the sudio FIFO underflow interrupt. Once set, this bit will remain high until the interrupt is cleared via
FIFO_UNDERFLO_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
FIFO_UNDERFLO_ST
0 (default)
1
FIFO_OVERFLO_ST, IO, Address 0x7F[5] (Read Only)
Latched status for the audio FIFO overflow interrupt. Once set, this bit will remain high until the interrupt is cleared via
FIFO_OVERFLO_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
FIFO_OVERFLO_ST
0 (default)
1
CTS_PASS_THRSH_ST, IO, Address 0x7F[4] (Read Only)
Latched status for the ACR CTS value exceed threshold interrupt. Once set, this bit will remain high until the interrupt is cleared via
CTS_PASS_THRSH_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
CTS_PASS_THRSH_ST
0 (default)
1
CHANGE_N_ST, IO, Address 0x7F[3] (Read Only)
Latched status for the ACR N value changed interrupt. Once set, this bit will remain high until the interrupt is cleared via
CHANGE_N_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
CHANGE_N_ST
0 (default)
1
Description
No new Audio InfoFrame received. Interrupt has not been generated.
Audio InfoFrame with new content received. Interrupt has been generated.
Description
Audio FIFO has not reached high threshold.
Audio FIFO has reached high threshold.
Description
Audio FIFO has not underflowed.
Audio FIFO has underflowed.
Description
Audio FIFO has not overflowed.
Audio FIFO has overflowed.
Description
Audio clock regeneration CTS value has not passed the threshold.
Audio clock regeneration CTS value has changed more than threshold.
Description
Audio clock regeneration N value has not changed.
Audio clock regeneration N value has changed.
Rev. A | Page 169 of 184
UG-180
