Analog Devices Advantiv ADV7611 Hardware User's Manual page 73

Hardware User Guide
Vendor Specific InfoFrame Registers
Table 18 provides a list of readback registers available for the vendor specific InfoFrame.
Table 18. VS InfoFrame Registers
InfoFrame Map Address
0xEC
0xED
0xEE
0x54
0x55
0x56
0x57
0x58
0x59
0x5A
0x5B
0x5C
0x5D
0x5E
0x5F
0x60
0x61
0x62
0x63
0x64
0x65
0x66
0x67
0x68
0x69
0x6A
0x6B
0x6C
0x6D
0x6E
0x6F
The vendor specific InfoFrame registers are considered valid if the following two conditions are met:
•
VS_INFO_RAW is 1.
•
VS_INF_CKS_ERR_RAW
VS_INFO_RAW , IO, Address 0x60[4] (Read Only)
Raw status signal of vendor specific InfoFrame detection signal.
Function
VS_INFO_RAW
0 (default)
1
R/W Register Name
R VS_PACKET_ID[7:0]
R VS_INF_VERS
R VS_INF_LEN
R VS_INF_PB_0_1
R VS_INF_PB_0_2
R VS_INF_PB_0_3
R VS_INF_PB_0_4
R VS_INF_PB_0_5
R VS_INF_PB_0_6
R VS_INF_PB_0_7
R VS_INF_PB_0_8
R VS_INF_PB_0_9
R VS_INF_PB_0_10
R VS_INF_PB_0_11
R VS_INF_PB_0_12
R VS_INF_PB_0_13
R VS_INF_PB_0_14
R VS_INF_PB_0_15
R VS_INF_PB_0_16
R VS_INF_PB_0_17
R VS_INF_PB_0_18
R VS_INF_PB_0_19
R VS_INF_PB_0_20
R VS_INF_PB_0_21
R VS_INF_PB_0_22
R VS_INF_PB_0_23
R VS_INF_PB_0_24
R VS_INF_PB_0_25
R VS_INF_PB_0_26
R VS_INF_PB_0_27
R VS_INF_PB_0_28
is 0. This condition applies only if
Description
No new VS InfoFrame has been received since the last HDMI packet detection reset.
A new VS InfoFrame has been received. This bit resets to zero after an HDMI packet detection reset or
upon writing to VS_PACKET_ID.
Rev. A | Page 73 of 184
Byte Name
Packet type value
InfoFrame version number
InfoFrame length
Checksum
Data Byte 1
Data Byte 2
Data Byte 3
Data Byte 4
Data Byte 5
Data Byte 6
Data Byte 7
Data Byte 8
Data Byte 9
Data Byte 10
Data Byte 11
Data Byte 12
Data Byte 13
Data Byte 14
Data Byte 15
Data Byte 16
Data Byte 17
Data Byte 18
Data Byte 19
Data Byte 20
Data Byte 21
Data Byte 22
Data Byte 23
Data Byte 24
Data Byte 25
Data Byte 26
Data Byte 27
ALWAYS_STORE_INF is set to 1.
UG-180
