Hardware User Guide
CEC_BUF0_RX_FRAME_LENGTH[4:0] , Addr 80 (CEC), Address 0x25[4:0] (Read Only)
Function
CEC_BUF0_RX_FRAME_LENGTH[4:0]
xxxxx
CEC_CLR_RX_RDY0 , Addr 80 (CEC), Address 0x2C[1] (Self-Clearing)
Clear control for CEC_RX_RDY0.
Function
CEC_CLR_RX_RDY0
0 (default)
1
Table 63. CEC Incoming Frame Buffer 1 Registers
Register Name
CEC_BUF1_RX_FRAME_HEADER[7:0]
CEC_BUF1_RX_FRAME_DATA0[7:0]
CEC_BUF1_RX_FRAME_DATA1[7:0]
CEC_BUF1_RX_FRAME_DATA2[7:0]
CEC_BUF1_RX_FRAME_DATA3[7:0]
CEC_BUF1_RX_FRAME_DATA4[7:0]
CEC_BUF1_RX_FRAME_DATA5[7:0]
CEC_BUF1_RX_FRAME_DATA6[7:0]
CEC_BUF1_RX_FRAME_DATA7[7:0]
CEC_BUF1_RX_FRAME_DATA8[7:0]
CEC_BUF1_RX_FRAME_DATA9[7:0]
CEC_BUF1_RX_FRAME_DATA10[7:0]
CEC_BUF1_RX_FRAME_DATA11[7:0]
CEC_BUF1_RX_FRAME_DATA12[7:0]
CEC_BUF1_RX_FRAME_DATA13[7:0]
CEC_BUF1_RX_FRAME_DATA14[7:0]
CEC_BUF1_RX_FRAME_LENGTH[4:0] , Addr 80 (CEC), Address 0x64[4:0] (Read Only)
Function
CEC_BUF1_RX_FRAME_LENGTH[4:0]
xxxxx
CEC_CLR_RX_RDY1 , Addr 80 (CEC), Address 0x2C[2] (Self-Clearing)
Clear control for CEC_RX_RDY1.
Function
CEC_CLR_RX_RDY1
0 (default)
1
Description
The total number of bytes (including header byte) that were received into Buffer 0
Description
Retain the value of the CEC_RX_RDY0 flag
Clear the value of the CEC_RX_RDY0 flag
CEC Map Address
0x54
0x55
0x56
0x57
0x58
0x59
0x5A
0x5B
0x5C
0x5D
0x5E
0x5F
0x60
0x61
0x62
0x63
Description
The total number of bytes (including header byte) that were received into buffer 1
Description
Retain the value of the CEC_ RX_RDY1 flag
Clear the value of the CEC_RX_RDY1 flag
Rev. A | Page 145 of 184
Description
Header of message in Frame Buffer 1
Byte 0 of message in Frame Buffer 1
Byte 1 of message in Frame Buffer 1
Byte 2 of message in Frame Buffer 1
Byte 3 of message in Frame Buffer 1
Byte 4 of message in Frame Buffer 1
Byte 5 of message in Frame Buffer 1
Byte 6 of message in Frame Buffer 1
Byte 7 of message in Frame Buffer 1
Byte 8 of message in Frame Buffer 1
Byte 9 of message in Frame Buffer 1
Byte 10 of message in Frame Buffer 1
Byte 11 of message in Frame Buffer 1
Byte 12 of message in Frame Buffer 1
Byte 13 of message in Frame Buffer 1
Byte 14 of message in Frame Buffer 1
UG-180
