Hardware User Guide
RECOMMENDED SETTINGS FOR HDMI INPUTS
This section provides the recommended settings for an HDMI input encapsulating a video resolution corresponding to a selection Video
ID Code described in the 861 specification.
Table 7 provides the recommended settings for the following registers:
•
PRIM_MODE
•
VID_STD
•
V_FREQ (V_FREQ should be set to 0x0 if not specified in Table 7.)
•
INV_HS_POL = 1 (INV_HS_POL should be set to 1 if not specified in Table 7.)
•
INV_VS_POL = 1 (INV_VS_POL should be set to 1 if not specified in Table 7.)
Table 7. Recommended Settings for HDMI Inputs
Video ID Codes
(861 Specification) Formats
2, 3 720 × 480p @ 60 Hz
4 1280 × 720p @ 60 Hz
5 1920 × 1080i @ 60 Hz
6, 7 720 (1440) × 480i @ 60 Hz
10, 11 2880 × 480i @ 60 Hz
14, 15 1440 × 480p @ 60 Hz
16 1920 × 1080p @ 60 Hz
17, 18 720 × 576p @ 60 Hz
19 1280 × 720p @ 50 Hz
20 1920 × 1080i @ 50 Hz
21, 22 720 (1440) ×576i @ 60 Hz
25, 26 2880 × 480i @ 60 Hz
29, 30 144 0× 576p @ 60 Hz
31 1920 × 1080p @ 50 Hz
32 1920 × 1080p @ 24 Hz
33 1920 × 1080p @ 25 Hz
35, 36 2880 × 480p @ 60 Hz
37, 38 2880 × 576p @ 60 Hz
Recommended Settings
Pixel if Free Run Used and
Repetition DIS_AUTO_PARAM_BUFF = 0
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
1 PRIM_MODE = 0x6
VID_STD = 0x2
3 PRIM_MODE = 0x6
VID_STD = 0x2
1 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
1 PRIM_MODE = 0x6
VID_STD = 0x2
3 PRIM_MODE = 0x6
VID_STD = 0x2
1 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
0 PRIM_MODE = 0x6
VID_STD = 0x2
3 PRIM_MODE = 0x6
VID_STD = 0x2
3 PRIM_MODE = 0x6
VID_STD = 0x2
Rev. A | Page 23 of 184
UG-180
Recommended Settings
if Free Run Not Used
or Free Run Used and
DIS_AUTO_PARAM_BUFF = 1
PRIM_MODE = 0x5
VID_STD = 0xA
PRIM_MODE = 0x5
VID_STD = 0x13
PRIM_MODE = 0x5
VID_STD = 0x14
PRIM_MODE = 0x5
VID_STD = 0x0
PRIM_MODE = 0x5
VID_STD = 0x0
PRIM_MODE=0x5
VID_STD = 0xA
PRIM_MODE = 0x5
VID_STD = 0x1E
PRIM_MODE = 0x5
VID_STD = 0xB
PRIM_MODE = 0x5
VID_STD = 0xA3
V_FREQ = 0x1
PRIM_MODE = 0x5
VID_STD = 0x14
V_FREQ = 0x1
PRIM_MODE = 0x5
VID_STD = 0x1
PRIM_MODE=0x5
VID_STD = 0x1
PRIM_MODE = 0x5
VID_STD = 0xA
PRIM_MODE = 0x5
VID_STD = 0x1E
V_FREQ = 0x1
PRIM_MODE = 0x5
VID_STD = 0x1E
V_FREQ = 0x4
PRIM_MODE = 0x5
VID_STD = 0x1E
V_FREQ = 0x3
PRIM_MODE = 0x5
VID_STD = 0xA
PRIM_MODE = 0x5
VID_STD = 0xA
