CP Synchronization Signals
The three primary synchronization signals have certain default positions, depending on the video standard in use.
To allow for a glueless interface to downstream ICs, there is the facility to adjust the position of edges on the three primary
synchronization signals. Figure 49, Figure 50, Figure 51, Figure 52, Figure 53, Figure 54, Figure 55, and Figure 56 show the nominal
position of HS, VS, and FIELD. The positions of those signals can be adjusted in both directions by using the following controls:
•
START_HS[9:0]
•
END_HS[9:0]
•
START_VS[3:0]
•
END_VS[3:0]
•
START_VS_EVEN[3:0]
•
START_FE[3:0]
•
START_FO[3:0]
All six above parameters are given as signed values. This means that rather than adjusting the absolute position of a signal, these
adjustments allow the user to advance (negative value) or delay (positive value) the respective timing reference signals.
In addition, the polarity of the synchronization output signals can be inverted by using:
•
INV_HS_POL
•
INV_F_POL
•
INV_VS_POL
HSync Timing Controls
Programming the registers listed in this section, the HS signal as shown in Figure 49 can be adjusted in the described manner.
Table 48. HS Default Timing
Symbol Characteristic
a HS to start of active video
d HS width
b Active video samples
c Total samples/line
Table 49. HS Default Timing (Continued, 1)
Symbol Characteristic
a HS to start of active
video
d HS width
b Active video samples
c Total samples/line
Table 50. HS Default Timing (Continued, 2)
Symbol Characteristic
a HS to start of active video
d HS width
b Active video samples
c Total samples/line
Table 51. HS Default Timing (Continued, 3)
Symbol Characteristic
a HS to start of active video
d HS width
b Active video samples
c Total samples/line
Note 525i
Default 118
Default 64
720
858
Note 680 × 480 at 60 Hz
Default 140
Default 96
640
800
800 × 600
Note at 56 Hz
Default 196
Default 72
800
1024
Note 1024 × 768 at 60 Hz
Default 292
Default 136
1024
1344
