Hardware User Guide
CS_DATA[1] , PCM/non-PCM Audio Sample, HDMI Map, Address 0x36[1]
Function
CS_DATA[1]
0 (default)
1
CS_DATA[2] , Copyright, HDMI Map, Address 0x36[2]
Function
CS_DATA[2]
0 (default)
1
CS_DATA[5:3] , Emphasis, HDMI Map, Address 0x36[5:3]
Function
1
CS_DATA[5:3]
000 (default)
001
1
Unspecified values are reserved.
CS_DATA[7:6] , Channel Status Mode, HDMI Map, Address 0x36[7:6]
Function
1
CS_DATA[7:6]
00 (default)
1
Unspecified values are reserved.
Category Code
The category code is specified in Byte 1 of the channel status. The category code indicates the type of equipment that generates the digital
audio interface signal. For more information, refer to the IEC60958 standards.
CS_DATA[15:8] , Category Code, HDMI Map, Address 0x37[7:0]
Function
CS_DATA[15:8]
xxxx xxxx
0000 0000 (default)
1
Refer to IEC60958-3 standards.
Source Number and Channel Number
CS_DATA[19:16] , Source Number, HDMI Map, Address 0x38[3:0]
Function
CS_DATA[19:16]
xxxx
0000 (default)
1
Refer to IEC60958-3 standards.
CS_DATA[23:20] , Channel Number, HDMI Map, Address 0x38[7:4]
Function
CS_DATA[23:20]
xxxxx
00000 (default)
1
Refer to IEC60958-3 standards.
Description
Audio sample word represents linear PCM samples
Audio sample word used for other purposes
Description
Software for which copyright is asserted
Software for which no copyright is asserted
Description
Two audio channels without pre-emphasis
Two audio channels with 50/15 pre-emphasis
Description
Mode 0
Description
1
Category code
Reset value
Description
1
Source number
Reset value
Description
Channel number 1
Reset value
Rev. A | Page 65 of 184
UG-180
