Hardware User Guide
PARITY_ERROR_ST , IO, Address 0x84[4] (Read Only)
Latched status of parity error interrupt. Once set, this bit will remain high until the interrupt is cleared via PARITY_ERROR_CLR. This
bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
PARITY_ERROR_ST
0 (default)
1
NEW_SAMP_RT_ST , IO, Address 0x84[3] (Read Only)
Latched status of new sampling rate interrupt. Once set, this bit will remain high until the interrupt is cleared via NEW_SAMP_RT_CLR.
This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
NEW_SAMP_RT_ST
0 (default)
1
AUDIO_FLT_LINE_ST , IO, Address 0x84[2] (Read Only)
Latched status of new TMDS frequency interrupt. Once set, this bit will remain high until the interrupt is cleared via
NEW_TMDS_FREQ_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
AUDIO_FLT_LINE_ST
0 (default)
1
NEW_TMDS_FRQ_ST , IO, Address 0x84[1] (Read Only)
Latched status of new TMDS frequency interrupt. Once set, this bit will remain high until the interrupt is cleared via
NEW_TMDS_FREQ_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
NEW_TMDS_FRQ_ST
0 (default)
1
FIFO_NEAR_UFLO_ST , IO, Address 0x84[0] (Read Only)
Latched status for the audio FIFO near underflow interrupt. Once set, this bit will remain high until the interrupt is cleared via
FIFO_UFLO_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
FIFO_NEAR_UFLO_ST
0 (default)
1
HDMI Edg Status 4 register consists of fields: MS_INF_CKS_ERR_ST, SPD_INF_CKS_ERR_ST, AUD_INF_CKS_ERR_ST,
AVI_INF_CKS_ERR_ST, RI_EXPIRED_A_ST, and AKSV_UPDATE_A_ST.
MS_INF_CKS_ERR_ST , IO, Address 0x89[7] (Read Only)
Latched status of MPEG source InfoFrame checksum error interrupt. Once set, this bit will remain high until the interrupt is cleared via
MS_INF_CKS_ERR_CLR. This bit is only valid if enabled via the corresponding INT1 or INT2 interrupt mask bit.
Function
MS_INF_CKS_ERR_ST
0 (default)
1
Description
No parity error detected in audio packets
Parity error detected in an audio packet
Description
Sampling rate bits of the channel status data on Audio Channel 0 have not changed.
Sampling rate bits of the channel status data on Audio Channel 0 have changed.
Description
Audio sample packet with flat line bit set has not been received.
Audio sample packet with flat line bit set has been received.
Description
TMDS frequency has not changed by more than tolerance.
TMDS frequency has changed by more than tolerance.
Description
Audio FIFO has not reached low threshold.
Audio FIFO has reached low threshold.
Description
No change in MPEG source InfoFrame checksum error
An MPEG source InfoFrame checksum error has triggered this interrupt
