ISRC1_PACKET_ID[7:0] , Addr 7C (InfoFrame), Address 0xF2[7:0]
ISRC1 InfoFrame ID.
Function
ISRC1_PACKET_ID[7:0]
0xxxxxxx
1xxxxxxx
ISRC2_PACKET_ID[7:0] , Addr 7C (InfoFrame), Address 0xF5[7:0]
ISRC2 InfoFrame ID.
Function
ISRC2_PACKET_ID[7:0]
0xxxxxxx
1xxxxxxx
GAMUT_PACKET_ID[7:0] , Addr 7C (InfoFrame), Address 0xF8[7:0]
Gamut InfoFrame ID.
Function
GAMUT_PACKET_ID[7:0]
0xxxxxxx
1xxxxxxx
Note: The packet type values and corresponding packets should not be programmed in the packet type values registers. These packets are
always processed internally and cannot be stored in the packet/InfoFrame registers in the InfoFrame map:
•
0x01: audio clock regeneration packet
•
0x02: audio sample packet
•
0x03: general control packet
•
0x07: DSD audio sample packet
•
0x08: DST audio packet
•
0x09: HBR audio stream packet
REPEATER SUPPORT
The ADV7611 incorporates an EDID/repeater controller that provides all the features required for a receiver front end of a fully
HDCP 1.4 compliant repeater system. The ADV7611 has a RAM that can store up to 127 KSVs, which allows it to handle up to
127 downstream devices in repeater mode (refer to Table 23).
The ADV7611 features a set of HDCP registers, defined in the HDCP specifications, which are accessible through the DDC bus (refer to
the DDC Ports section) of the selected port. A subset of the HDCP registers (defined in the following subsections) are also available in the
Repeater Map and are accessible through the main I
Repeater Routines Performed by the EDID/Repeater Controller
Power-Up
A power-on reset circuitry on the DVDD supply is used to reset the EDID/repeater controller when the ADV7611 is powered up. When
the EDID/repeater controller reboots after reset, it resets all the KSV registers listed in Table 23 to 0x00.
AKSV Update
The EDID/repeater controller resets automatically the BCAPS [5] bit to 0 when an HDCP transmitter writes its AKSV into the ADV7611
HDCP registers through the DDC bus of the HDMI port.
Note: Writing a value in the AKSV[39:32] triggers an AKSV update and AKSV_UPDATE_ST interrupt if AKSV_UPDATE_MB1 or
AKSV_UPDATE_MB2 has been set to 1 This triggers the EDID/repeater controller to reset the BCAPS [5] bit back to 0.
KSV List Ready
The KSV_LIST_READY bit is set by an external controller driving the ADV7611. This notifies the ADV7611 on-chip EDID/repeater
controller that the KSV list registers have been updated with the KSV's of the attached and active downstream HDCP devices.
Description
Packet type value of packet stored in InfoFrame map, Address 0x8C to 0xA7
Packet type value of InfoFrame stored in InfoFrame map, Address 0x8C to 0xA7
Description
Packet type value of packet stored in InfoFrame map, Address 0xA8 to 0xC3
Packet type value of InfoFrame stored in InfoFrame map, Address 0xA8 to 0xC3
Description
Packet type value of packet stored in InfoFrame map, Address 0xC4 to 0xDF
Packet type value of InfoFrame stored in InfoFrame map, Address 0xC4 to 0xDF
2
C port (refer to the Main I2C Port section).
