Hardware User Guide
DE_V_END[3:0] , Addr 44 (CP), Address 0x8E[3:0]
A control to vary the position of the end of the VBI region.
This register stores a signed value represented in a twos complement format. The unit of DE_V_START[9:0] is one line.
Function
DE_V_END[3:0]
1000
1111
0000 (default)
0001
0111
DE_V_START_EVEN[3:0] , Addr 44 (CP), Address 0x88[7:4]
A control to vary the start position of the VBI region in even field.
This register stores a signed value represented in a twos complement format. The unit of DE_V_START_EVEN[9:0] is one pixel clock.
Function
DE_V_START_EVEN[3:0]
Range
DE_V_END_EVEN[3:0], Addr 44 (CP), Address 0x88[3:0]
A control to vary the position of the end of the VBI region in even field.
This register stores a signed value represented in a twos complement format. The unit of DE_V_END_EVEN[9:0] is one pixel clock.
Function
DE_V_END_EVEN[3:0]
Range
FIELD Timing Controls
Programming of the FIELD timing signals is listed in this section. The FIELD signal, shown in Figure 50, Figure 51, Figure 52, and
Figure 55, can be adjusted in the described manner. (Progressive systems do not have a FIELD signal.)
Table 57. FIELD Default Timing
Characteristic
START_FO
END_FO range maximum
START_FO
END_FO range maximum
START_FE[3:0] , Addr 44 (CP), Address 0x80[7:4]
A control to shift the position of the start of even field edge of the FIELD signal output by the CP core.
This register stores a signed value in a twos complement format. START_FE[3:0] the number of lines by which the start of the even fields
edge of the FIELD signal is shifted (for example, 0x0D corresponds to a shift of three lines toward the active video, 0x05 corresponds to a
shift of five lines away from the active video).
Function
START_FE[3:0] Description
0x0 (default) Default value.
0x0 to 0x7 The edge of the FIELD signal corresponding to the start of the even field is shifted toward the active video.
0x8 to 0xF The trailing of the FIELD signal corresponding to the start of the even field is shifted away from the active video.
Description
−8 lines of shift
−1 line of shift
Default
+1 line of shift
+7 lines of shift
Description
−8 to +7 lines
Description
−8 to +7 lines
Units 525i 625i
Line 7 7
Line 8 8
Rev. A | Page 129 of 184
525p 625p 720p
N/A N/A N/A
N/A N/A N/A
UG-180
1080i
7
8
