Analog Devices Advantiv ADV7611 Hardware User's Manual page 130

UG-180
Table 58. Controlling the Even Field Section of the FIELD Timing Signal
START_FE[3:0] Hex
0000(default) 0x0
0001 0x1
0011 0x3
0111 0x7
1111 0xF
1101 0xD
1000 0x8
1 Closer to active video.
2 Away from active video.
START_FO[3:0] , Addr 44 (CP), Address 0x80[3:0]
A control to shift the position of the start of odd field edge of the FIELD signal output by the CP core.
This register stores a signed value in a twos complement format. START_FO[3:0] the number of lines by which the start of the odd fields
edge of the FIELD signal is shifted (for example, 0x0D corresponds to a shift of 3 lines toward the active video, 0x05 corresponds to a shift
of 5 line away from the active video).
Function
START_FO[3:0] Description
0x0 (default) Default value.
0x0 to 0x7 The edge of the FIELD signal corresponding to the start of the odd field is shifted toward the active video.
0x8 to 0xF The trailing of the FIELD signal corresponding to the start of the odd field is shifted away from the active video.
Table 59. Controlling the Odd Field Section of FIELD Timing Signal
START_FO[3:0] Hex
0000 (default) 0x0
0001 0x1
0011 0x3
0111 0x0
1111 0xF
1101 0xD
1000 0x8
1
Closer to active video.
2 Away from active video.
Result
No move (default)
1
1 HS shift later than default
3 HS shift later than default
7 HS shift later than default
1 HS shift earlier than default
3 HS shift earlier than default
8 HS shift earlier than default
Result
No move (default)
1
1 HS shift later than default
3 HS shift later than default
7 HS shift later than default
1 HS shift earlier than default
3 HS shift earlier than default
8 HS shift earlier than default
Rev. A | Page 130 of 184
Hardware User Guide
Note
Minimum →
Maximum →
Minimum ←
2
Maximum ←
Note
Minimum →
Maximum →
Minimum ←
2
Maximum ←
