USING THE ADV7611 HARDWARE USER GUIDE
NUMBER NOTATIONS
Table 1.
Notation Description
Bit N Bits are numbered in little endian format, that is, the least significant bit of a number is referred to as Bit 0.
V[X:Y] Bit field representation covering Bit X to Bit Y of a value or a field (V).
0xNN Hexadecimal (base-16) numbers are preceded by the prefix '0x' .
0bNN Binary (base-2) numbers are preceded by the prefix '0b' .
NN Decimal (base-10) are represented using no additional prefixes or suffixes.
REGISTER ACCESS CONVENTIONS
Table 2.
Mode Description
R/W Memory location has read and write access.
R Memory location is read access only. A read always returns 0 unless otherwise specified.
W Memory location is write access only.
ACRONYMS AND ABBREVIATIONS
Table 3.
Acronym/Abbreviation Description
ACP Audio content protection.
AGC Automatic gain control.
Ainfo HDCP register. Refer to digital content protection documentation in the References section.
AKSV HDCP transmitter key selection vector. Refer to digital content protection documentation in the References
section.
An 64-bit pseudo-random value generated by HDCP cipher function of Device A.
AP Audio output pin.
AVI Auxiliary video information.
BCAPS HDCP register. Refer to digital content protection documentation in the References section.
BKSV HDCP receiver key selection vector. Refer to digital content protection documentation in the References section.
CP Component processor.
CSC Color space converter/conversion.
DDR Double data rate.
DE Data enable.
DLL Delay locked loop.
DPP Data preprocessor.
DVI Digital visual interface.
EAV End of active video.
EMC Electromagnetic compatibility.
EQ Equalizer.
HD High definition.
HDCP High bandwidth digital content protection.
HDMI High bandwidth multimedia interface.
HDTV High definition television.
HPA Hot plug assert.
HPD Hot plug detect.
HSync Horizontal synchronization.
IC Integrated circuit.
ISRC International standard recording code.
2
I S Inter IC sound.
