UG-180
Group 3 HDMI Interrupts
The interrupts listed in Table 68 are valid under the following conditions:
•
ADV7611 is configured in HMDI mode
•
TMDS_CLK_A_RAW is set to 1 if Port A is the active HDMI port
•
TMDSPLL_LCK_A_RAW is set to 1
Table 68. HDMI Interrupts Group 3
Interrupts
ISRC2_PCKT
ISRC1_PCKT
ACP_PCKT
VS_INFO
MS_INFO
SPD_INFO
AUDIO_INFO
AVI_INFO
CS_DATA_VALID
AV_MUTE
AUDIO_CH_MD
AUDIO_MODE_CHNG
GEN_CTL_PCKT
AUDIO_C_PCKT
GAMUT_MDATA
V_LOCKED
DE_REGEN_LCK
HDMI_MODE
HDMI_ENCRPT_A
NEW_ISRC2_PCKT
NEW_ISRC1_ PCKT
NEW_ACP_PCKT
NEW_VS_INFO
NEW_MS_INFO
NEW_SPD_INFO
NEW_AUDIO_INFO
NEW_AVI_INFO
FIFO_NEAR_OVFL
CTS_PASS_THRSH
CHANGE_N
PACKET_ERROR
AUDIO_PCKT_ERR
NEW_GAMUT_MDATA
DEEP_COLOR_CHNG
VCLK_CHNG
PARRITY_ERROR
NEW_SAMP_RT
AUDIO_FLT_LINE
NEW_TMDS_FRQ
FIFO_NEAR_UFLO
VIDEO_3D_RAW
RI_EXPIRED_A_RAW
