11
VLAN Configuration
Command Attributes (CLI)
• VLAN – ID of configured VLAN (1-4093, no leading zeroes).
• Type – Shows how this VLAN was added to the switch.
- Dynamic: Automatically learned via GVRP.
- Static: Added as a static entry.
• Name – Name of the VLAN (1 to 32 characters).
• Status – Shows if this VLAN is enabled or disabled.
- Active: VLAN is operational.
- Suspend: VLAN is suspended; i.e., does not pass packets.
• Ports / Channel groups – Shows the VLAN interface members.
CLI – Current VLAN information can be displayed with the following command.
Console#show vlan id 1
VLAN ID:
Type:
Name:
Status:
Ports/Port Channels:
Console#

Creating VLANs

Use the VLAN Static List to create or remove VLAN groups. To propagate
information about VLAN groups used on this switch to external network devices, you
must specify a VLAN ID for each of these groups.
Command Attributes
• Current – Lists all the current VLAN groups created for this system. Up to 4093
VLAN groups can be defined. VLAN 1 is the default untagged VLAN.
• New – Allows you to specify the name and numeric identifier for a new VLAN
group. (The VLAN name is only used for management on this system; it is not
added to the VLAN tag.)
• VLAN ID – ID of configured VLAN (1-4093).
• VLAN Name – Name of the VLAN (1 to 32 characters).
• Status (Web) – Enables or disables the specified VLAN.
- Enable: VLAN is operational.
- Disable: VLAN is suspended; i.e., does not pass packets.
11-6
1
Static
DefaultVlan
Active
Eth2/ 1(S) Eth2/ 2(S) Eth2/ 3(S) Eth2/ 4(S) Eth2/ 5(S)
Eth2/ 6(S) Eth2/ 7(S) Eth2/ 8(S) Eth2/ 9(S) Eth2/10(S)
Eth2/11(S) Eth2/12(S) Eth2/13(S) Eth2/14(S) Eth2/15(S)
Eth2/16(S) Eth2/17(S) Eth2/18(S) Eth2/19(S) Eth2/20(S)
Eth2/21(S) Eth2/22(S) Eth2/23(S) Eth2/24(S) Eth2/25(S)
Eth2/26(S) Eth2/27(S) Eth2/28(S) Eth2/29(S) Eth2/30(S)
Eth2/31(S) Eth2/32(S) Eth2/33(S) Eth2/34(S) Eth2/35(S)
Eth2/36(S) Eth2/37(S) Eth2/38(S) Eth2/39(S) Eth2/40(S)
Eth2/41(S) Eth2/42(S) Eth2/43(S) Eth2/44(S) Eth2/45(S)
Eth2/46(S) Eth2/47(S) Eth2/48(S) Eth2/49(S) Eth2/50(S)
34-13
