Figure 20-1 Rip General Settings - SMC Networks TigerStack II SMC8926EM Management Manual

20
Unicast Routing
Web - Click Routing Protocol, RIP, General Settings. Enable or disable RIP, set the
RIP version used on previously unset interfaces to RIPv1 or RIPv2, set the basic
update timer, and then click Apply.
CLI - This example sets the router to use RIP Version 2, and sets the basic timer to
15 seconds.
Console(config)#router rip
Console(config-router)#version 2
Console(config-router)#timers basic 15
Console(config-router)#end
Console#show rip globals
RIP Process: Enabled
Update Time in Seconds: 15
Number of Route Change: 0
Number of Queries: 1
Console#
20-4

Figure 20-1 RIP General Settings
