• 802.1X Port Details – Displays the port access control parameters for each
interface, including the following items:
- reauth-enabled
- reauth-period
- quiet-period
- tx-period
- supplicant-timeout
- server-timeout
- reauth-max
- max-req
- Status
- Operation Mode
- Max Count
- Port-control
- Supplicant
- Current Identifier
• Authenticator State Machine
- State
- Reauth Count
• Backend State Machine
- State
- Request Count
- Identifier(Server)
• Reauthentication State Machine
- State
802.1X Port Authentication
– Periodic re-authentication (page 25-30).
– Time after which a connected client must be
re-authenticated (page 25-31).
– Time a port waits after Max Request Count is
exceeded before attempting to acquire a new
client (page 25-31).
– Time a port waits during authentication session
before re-transmitting EAP packet (page 25-32).
– Supplicant timeout.
– Server timeout.
– Maximum number of reauthentication attempts.
– Maximum number of times a port will retransmit
an EAP request/identity packet to the client
before it times out the authentication session
(page 25-27).
– Authorization status (authorized or not).
– Shows if single or multiple hosts (clients) can
connect to an 802.1X-authorized port.
– The maximum number of hosts allowed to
access this port (page 25-29).
– Shows the dot1x mode on a port as auto,
force-authorized, or force-unauthorized
(page 25-28).
– MAC address of authorized client.
– The integer (0-255) used by the Authenticator to
identify the current authentication session.
– Current state (including initialize, disconnected,
connecting, authenticating, authenticated,
aborting, held, force_authorized,
force_unauthorized).
– Number of times connecting state is re-entered.
– Current state (including request, response,
success, fail, timeout, idle, initialize).
– Number of EAP Request packets sent to the
Supplicant without receiving a response.
– Identifier carried in the most recent EAP
Success, Failure or Request packet received
from the Authentication Server.
– Current state (including initialize, reauthenticate).
