32
LLDP Commands
Command Usage
This option advertises Power-over-Ethernet capabilities, including whether or
not PoE is supported, currently enabled, if the port pins through which power
is delivered can be controlled, the port pins selected to deliver power, and the
power class.
Example
Console(config)#interface ethernet 1/1
Console(config-if)#lldp dot3-tlv poe
Console(config-if)#

show lldp config

This command shows LLDP configuration settings for all ports.
Syntax
show lldp config [detail interface]
• detail - Shows configuration summary.
• interface
• ethernet unit/port
- unit - Stack unit. (Range: 1-8)
- port - Port number. (Range: 1-26/50)
• port-channel channel-id (Range: 1-32)
Command Mode
Privileged Exec
Example
Console#show lldp config
LLDP Global Configuation
LLDP Enable
LLDP Transmit interval
LLDP Hold Time Multiplier
LLDP Delay Interval
LLDP Reinit Delay
LLDP Notification Interval : 5
LLDP Port Configuration
Interface |AdminStatus NotificationEnabled
--------- + ----------- -------------------
Eth 1/1 | Tx-Rx
Eth 1/2 | Tx-Rx
Eth 1/3 | Tx-Rx
Eth 1/4 | Tx-Rx
Eth 1/5 | Tx-Rx
. .
.
32-14
: Yes
: 30
: 4
: 2
: 2
True
True
True
True
True
