28
Link Aggregation Commands
Example
Console#show lacp 1 counters
Port Channel: 1
-------------------------------------------------------------------------
Eth 1/ 2
-------------------------------------------------------------------------
LACPDUs Sent
LACPDUs Receive
Marker Sent
Marker Receive
LACPDUs Unknown Pkts : 0
LACPDUs Illegal Pkts : 0
. .
.

Table 28-2 show lacp counters - display description

Field
LACPDUs Sent
LACPDUs Received
Marker Sent
Marker Received
LACPDUs Unknown Pkts Number of frames received that either (1) Carry the Slow Protocols Ethernet
LACPDUs Illegal Pkts
Console#show lacp 1 internal
Port Channel : 1
------------------------------------------------------------------------------
Oper Key : 3
Admin Key : 0
Eth 1/ 1
------------------------------------------------------------------------------
LACPDUs Internal
LACP System Priority : 32768
LACP Port Priority
Admin Key
Oper Key
Admin State
Oper State
. .
.
Field
Oper Key
Admin Key
LACPDUs Internal Number of seconds before invalidating received LACPDU information.
LACP System Priority LACP system priority assigned to this port channel.
28-8
: 12
: 6
: 0
: 0
Description
Number of valid LACPDUs transmitted from this channel group.
Number of valid LACPDUs received on this channel group.
Number of valid Marker PDUs transmitted from this channel group.
Number of valid Marker PDUs received by this channel group.
Type value, but contain an unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the Slow Protocols Ethernet
Type.
Number of frames that carry the Slow Protocols Ethernet Type value, but contain
a badly formed PDU or an illegal value of Protocol Subtype.
: 30 seconds
: 32768
: 3
: 3
: defaulted, aggregation, long timeout, LACP-activity
: distributing, collecting, synchronization, aggregation,
long timeout, LACP-activity

Table 28-3 show lacp internal - display description

Description
Current operational value of the key for the aggregation port.
Current administrative value of the key for the aggregation port.
