Command Usage
• LSAs have their age incremented by this delay before transmission. When
estimating the transmit delay, consider both the transmission and propagation
delays for an interface. Set the transmit delay according to link speed, using
larger values for lower-speed links.
• If this delay is not added, the time required to transmit an LSA over the link is
not taken into consideration by the routing process. On slow links, the router
may send packets more quickly than devices can receive them. To avoid this
problem, use the transmit delay to force the router to wait a specified interval
between transmissions.
Example
Console(config)#interface vlan 1
Console(config-if)#ip ospf transmit-delay 6
Console(config-if)#

show ip ospf

This command shows basic information about the routing configuration.
Command Mode
Privileged Exec
Example
Console#show ip ospf
Routing Process with ID 10.1.1.253
Supports only single TOS(TOS0) route
It is an area border and autonomous system boundary router
Redistributing External Routes from,
rip with metric mapped to 10
Number of area in this router is 2
Area 0.0.0.0 (BACKBONE)
Number of interfaces in this area is 1
SPF algorithm executed 19 times
Area 10.1.0.0
Number of interfaces in this area is 4
SPF algorithm executed 19 times
Console#
Field
Routing Process with ID
Supports only single TOS (TOS0) route
It is an router type
Number of areas in this router
Area identifier

Table 42-9 show ip ospf - display description

Description
Router ID
Type of service is not supported, so you can only assign one cost
per interface
The types displayed include internal, area border, or
autonomous system boundary routers
The number of configured areas
The area address, and area type if backbone, NSSA or stub
Open Shortest Path First (OSPF)
42
42-39
