12
Link Layer Discovery Protocol
This example displays detailed information for a specific port on the local switch.
Console#show lldp info local-device ethernet 1/1
LLDP Port Information Detail
Port : Eth 1/1
Port Type : MAC Address
Port ID : 00-00-E3-11-10-10
Port Desc : Ethernet Port on unit 1, port 1
Console#

Displaying LLDP Remote Port Information

Use the LLDP Remote Port/Trunk Information screen to display information about
devices connected directly to the switch's ports which are advertising information
through LLDP.
Field Attributes
• Local Port – The local port to which a remote LLDP-capable device is attached.
• Chassis ID – An octet string indicating the specific identifier for the particular
chassis in this system.
• Port ID – A string that contains the specific identifier for the port from which this
LLDPDU was transmitted.
• Port Name – A string that indicates the port's description. If RFC 2863 is
implemented, the ifDescr object should be used for this field.
• System Name – An string that indicates the system's administratively assigned
name.
Web – Click LLDP, Remote Port/Trunk Information.
12-8

Figure 12-7 LLDP Remote Port Information

32-15
