SMC Networks TigerStack II SMC8926EM Management Manual page 224

10
Spanning Tree Algorithm
---------------------------------------------------------------
Eth 1/ 7 information
---------------------------------------------------------------
Admin Status:
Role:
State:
External Admin Path Cost: 0
Internal Admin Path Cost: 0
External Oper Path Cost:
Internal Oper Path Cost:
Priority:
Designated Cost:
Designated Port:
Designated Root:
Designated Bridge:
Fast Forwarding:
Forward Transitions:
Admin Edge Port:
Oper Edge Port:
Admin Link Type:
Oper Link Type:
Spanning Tree Status:
. .
.
CLI – This example sets the priority for MSTI 1, and adds VLANs 1-5 to this MSTI.
Console(config)#spanning-tree mst-configuration
Console(config-mst)#mst 1 priority 4096
Console(config-mstp)#mst 1 vlan 1-5
Console(config-mst)#
10-18
Enabled
designate
forwarding
10000
10000
128
0
128.23
32768.0000E3111010
32768.0000E3111010
Disabled
2
Disabled
Disabled
auto
Point-to-point
Enabled
33-7
33-9
33-8
