2.4.3 Underside Panel

The underside panel features the router identification label and various perforations for different mounting options.
The figure below provides a detailed view of this panel:
Underside Panel
Fig. 4:
The underside panel includes the following elements:
Underside Panel Components
Item
A
B

2.5 Power Supply

The Regesta Smart PRO provides three distinct power supply options, depending on the specific model.
Note
Please ensure that you have identified your router model and carefully read the instructions before con-
necting the router!
Regesta Smart PRO
Description
Slots for the accessories to attach the device to a DIN rail mount. For further in-
formation on this accessory, please see the section titled
.
The platform on which the product information label is affixed. This label contains
details such as the device model, MAC address, serial number, and more.
2 Product Overview
Wall Mounting on page 18
