A.3.1.4 ASYNC
LED behavior for the ASYNC protocol
OFF
RED
YELLOW
GREEN
A.3.2 RS-485 Driver
The behavior of the LEDs depends on the protocols configured for the RS-485 interface.
A.3.2.1 SCADA MODBUS
LED behavior for CENTER mode.
OFF
RED
YELLOW
GREEN
LED behavior in REMOTE mode.
OFF
RED
YELLOW
GREEN
A.3.2.2 SCADA IEC-101
LED behavior in CENTER mode.
OFF
Regesta Smart PRO
The serial interface has not been detected/installed.
The serial interface is detected and the Control signal is either inactive or con-
figured as DOWN.
The serial interface is testing.
Steady: The Control signal is active, the interface is UP.
Flashing: Data is being transferred through the serial interface.
The serial interface has not been detected/installed or is configured as DOWN.
The serial interface has been detected and is awaiting data from the Central site
(serial). (Non-transparent mode)
The serial interface is detected and is awaiting data from the Central (serial) and/
or Remote sites (IP). (Transparent mode)
Steady: Data has been received from the Central site and transmitted to the Re-
mote site (IP). (Non-transparent mode)
Flashing: Data is being transferred through the serial interface. (Transparent and
non-transparent modes).
The serial interface has not been detected/installed or is configured as DOWN.
The serial interface has been detected and is awaiting data from the Central site
(IP). (Non-transparent mode)
The serial interface has been detected and is awaiting data from the Central (IP)
and/or Remote sites (serial). (Transparent mode)
Steady: Data has been received from the Central site and transmitted to the Re-
mote site (serial). (Non-transparent mode)
Flashing: Data is being transferred through the serial interface. (Transparent and
non-transparent modes).
The serial interface has not been detected/installed or is configured as DOWN.
