3 Components and Power Supply
D
E
F

3.1.3 Side Panels

Up to four antenna connectors are located on the side panels.
Side panels
Fig. 3:
The connectors are as follows:
Side panel connectors
Item
ANT1
ANT2
ANT3
ANT4

3.1.4 Underside Panel

The following elements can be found on the underside panel:
8
Kensington security slot
For further information, please see
page 9.
Reset. Reset button.
For further information on how the reset button works, please see
on page 13.
SIM Card 1-2. Slot where you can insert the SIM cards.
Refer to Installing the SIM card
tion.
Description
Antenna connectors.
For more information on the WWAN interface, refer to:
- Connecting the WWAN Antennas
- WWAN Connector on page 27
- Wireless WAN interface on page 30
Standalone and anti-theft security cable
on page 17 for more information on SIM installa-
on page 15
Teldat S.A.
on
RESET Button
Teldat Connect-4GePlus
