The Regesta Smart PRO features independent modules for the Wireless WAN interface, allowing you to choose
modules from different manufacturers or multiple modules from the same provider, depending on the technology
used. Typically, firmware is separate from the software. To ensure the correct update, consult your distributor for the
appropriate UPGRADE file specific to your Wireless WAN module, as detailed in the "Teldat Dm781-I Cellular Inter-
face" manual, which offers instructions for module upgrades.

4.7.1 Establishing a Connection to the Router

There are two methods available for accessing the device's Command Line Interface (CLI):
4.7.1.1 Connecting Via the Local Console (CONF Connector)
The Regesta Smart PRO features a convenient RJ45 female connector labeled CONF on its front panel, providing
access to the device's local console. To use this, connect the CONF port to an asynchronous terminal or a PC with
terminal emulation software.
To connect to the configuration port, use the provided RJ45 cable and the female RJ45-to-female DB9 adapter in-
cluded with the router. If your terminal uses DB25 connectors, an additional adapter will be required.
Connecting for Configuration
Fig. 18:
4.7.1.2 Connecting Via an IP Terminal (WAN Connector)
When connecting through an IP terminal, the Regesta Smart PRO will automatically use its default configuration if no
prior setup has been done.
The default settings are:
Note
Certain devices may leave the factory with custom settings, which could result in a different default con-
figuration than listed above.
To access the device's configuration console using the Telnet IP protocol, follow these steps:
Regesta Smart PRO
• Via the CONF connector.
• Using the Telnet protocol.
• Speed: 115200 bps.
• Data bits: 8
• Stop bits: 1.
• Parity bits: None.
• No flow control.
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
