- Page 1 Manual Teldat S.A. Regesta Smart PRO Installation Manual Copyright© Teldat Dm1002-I Version 1.6 10/2024 Teldat S.A. Regesta Smart PRO...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Power Source ........4.1.1 Power Connector Pins....... . . Regesta Smart PRO... - Page 4 WWAN/RF Connectors ....... . A.1.6 Configuration Connector ....... . Regesta Smart PRO...
- Page 5 Radio Information ....... . . 46 RF WWAN Specifications ....... Regesta Smart PRO...
-
Page 6: Chapter 1 About This Manual
The content in this manual applies specifically to the Regesta Smart PRO Series routers. 1.2 Who Should Read This Manual? This manual is designed for individuals who are installing and configuring the Regesta Smart PRO router for the first time. Installers should have a basic understanding of network structures, terminology, and concepts. -
Page 7: Safety Warnings
1 About This Manual Teldat S.A. 1.8 Safety Warnings "DC-powered device" "AC-powered device" Regesta Smart PRO... - Page 8 1 About This Manual Teldat S.A. Regesta Smart PRO...
-
Page 9: Related Documentation
1 About This Manual Teldat S.A. 1.9 Related Documentation Teldat Dm704-I Configuration and Monitoring Teldat Dm709-I LAN Interfaces Teldat Dm712-I SNMP Agent Teldat Dm781-I Cellular Interface Teldat Dm748-I Software Updating Teldat Dm753-I Syslog Client 1.10 Technical Support Contact information: Web: http://www.teldat.com Tel.: +34 918 076 565... -
Page 10: Chapter 2 Product Overview
2 Product Overview Teldat S.A. Chapter 2 Product Overview This chapter provides an overview of the features of Regesta Smart PRO routers and their components. It includes information on: • General Description on page 5 • Device Models on page 6 •... -
Page 11: Device Models
Code Description (Regulatory model) RWRTHR2ZAC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, AC powered (110 - 240 VAC). (TLDPH04D1) RWRTHR2ZDC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, DC powered (12 - 72 VDC). -
Page 12: Hardware Features
VAC). RWRTHR2LAC Regesta Smart PRO 1 LAN Gigabit Ethernet port, 1 WAN Combo Gigabit Ethernet port, 1 RS232, 1xWWAN (Bands: LTE 1, 3, 5, 7, 8, 20, 38, 40, 41 - WCDMA 1, 5, 8 - GSM 3, 8), (TLDPH00D1) AC powered (110 - 240 VAC). -
Page 13: Components
2.4 Components 2.4.1 Front Panel The front panel is equipped with various status LEDs to provide visual indications of the device's operating status. Refer to the figure below for a detailed view of the front panel layout. Regesta Smart PRO... - Page 14 SIM. Coverage level below -100dBm. Amber Coverage level between -90dBm and -100dBm. Green Coverage level above -90dBm. Ethernet LAN inter- The Ethernet LAN is either disabled or not connected. face Ethernet connection (link) established: Regesta Smart PRO...
-
Page 15: Connector Panel
Removing/Installing the Connector Pro- tector on page 15. The figure below illustrates the connector panel, which includes all the connectors available on the Regesta Smart PRO router. Regesta Smart PRO... - Page 16 38 WAN Gigabit Ethernet. RJ45 connector. For more information regarding the WAN interface with the Base-T connector, please refer WAN Connections on page 22 WAN Base-T Connector on page 35 WAN Base-T Interface on page 38 Regesta Smart PRO...
- Page 17 35 LAN Interface on page 38 POWER. Power connection. The Regesta Smart PRO can be powered by either AC or DC power sources, depending on the specific model. For details on power connection options, please refer to: Power Source on page 20.
-
Page 18: Underside Panel
MAC address, serial number, and more. 2.5 Power Supply The Regesta Smart PRO provides three distinct power supply options, depending on the specific model. Note Please ensure that you have identified your router model and carefully read the instructions before con-... -
Page 19: Ac Power Supply
12-72 V DC. 2.5.3 Multi-Range (MR) Power Supply The MR version of the Regesta Smart PRO can be powered by either DC or AC voltages, with supported nominal voltages of 110-240 V AC and 48 V DC. 2.5.4 Dying Gasp Option The different versions of the Regesta Smart PRO can be enhanced with an optional Dying Gasp board, which sends an alarm signal during power failures or if the power supply cable is removed. -
Page 20: Chapter 3 Installing The Router
3 Installing the Router Teldat S.A. Chapter 3 Installing the Router This chapter describes the steps to successfully install the Regesta Smart PRO router. It is divided into the following sections: • Workplace Conditions on page 15 • Removing/Installing the Connector Protector on page 15 •... - Page 21 3 Installing the Router Teldat S.A. Slide the case up as shown below: Regesta Smart PRO...
-
Page 22: Installing A Din Rail Mount
3.3 Installing a DIN Rail Mount The Regesta Smart PRO includes a DIN rail kit for mounting. This kit consists of two screws to attach the DIN rail to the underside of the device. You can secure the DIN rail in... -
Page 23: Wall Mounting
Fig. 6: 3.4 Wall Mounting The Regesta Smart PRO features three wall-mounting holes. To ensure secure attachment, screws must be installed in these holes. Before mounting the device on the wall, please remove the protective casing. Refer to the image below for the exact location of the fastening holes:... - Page 24 3 Installing the Router Teldat S.A. Fig. 7: Wall-Mounting Holes. Regesta Smart PRO...
-
Page 25: Chapter 4 Connecting The Router
4 Connecting the Router Teldat S.A. Chapter 4 Connecting the Router This chapter offers a detailed guide on connecting the Regesta Smart PRO router to Ethernet devices and networks. The following sections are included within this chapter: • Power Source on page 20 •... -
Page 26: Power Connector Cable
Uninterruptible Power Supply (UPS), a regulated power supply, or oper- ates independently from other systems (such as lighting). This practice helps to avoid malfunctions and premature wear of drivers and other components. Regesta Smart PRO... -
Page 27: Connecting
Fig. 10: 4.2.2 WAN Connections The Regesta Smart PRO features a single Ethernet COMBO Gigabit interface for WAN connections, with two con- nectors: an SFP for optical links and an RJ45 for 10/100/1000 Base-T links. These connectors cannot be used simul- taneously. -
Page 28: 4-Port Ethernet Switch Connections
4.2.3 4-Port Ethernet Switch Connections Certain models of the Regesta Smart PRO router are equipped with a 4-port 10/100/1000 Base-T switch, enabling automatic MDI/MDIX connection to a local area network (LAN). Be sure to carefully observe the labeling to avoid confusing this switch with other ports:... -
Page 29: Wwan Antenna Connections (Rf Connectors)
4.2.4 WWAN Antenna Connections (RF Connectors) Certain models of the Regesta Smart PRO router are equipped with a pair of RF antenna connectors. The antennas can be easily attached and detached by securely screwing and unscrewing them into the designated RF1 or RF2 connectors on the device's connector panel. - Page 30 For best results, it is recommended to use radio frequency accessories, such as antennas and cables, specifically endorsed by Teldat. Teldat offers a range of accessories, including 90º mount antennas, outdoor and ceiling installation antennas, exten- sion cables, and more. These accessories provide flexibility for installing the devices in various locations.
-
Page 31: Serial Port Connections
The optional Asynchronous Serial Port feature requires additional hardware. Some models include two extra serial ports, accessible via two RJ45 connectors on the Regesta Smart PRO. Note that the functionality of these ports may vary by model. To check if your device includes serial ports and their specifications, please refer to the label. -
Page 32: Installing The Sim Card
4.3 Installing the SIM Card The Regesta Smart PRO includes a Wireless WAN interface that requires at least one SIM card for operation. However, in some countries, certain CDMA services offered by specific operators do not require a SIM card. -
Page 33: Identifying The Sim Trays
After removing the case, you will clearly see the elements illustrated below. The Regesta Smart PRO supports two SIM cards, offering flexibility for various configurations. For example, in- stalling two SIM cards allows one to function as a backup. To configure this setup, each SIM card must be assigned to its respective tray, as they have distinct configuration parameters. -
Page 34: Rst Button
WAN port. 4.5 Dying Gasp Alarm The Regesta Smart PRO offers an optional board that triggers an alarm in the event of a power outage or if the power supply cable is disconnected. -
Page 35: Troubleshooting
The Regesta Smart PRO router supports updating to the latest software releases. For detailed information about available updates, we recommend contacting your distributor. There are several methods for updating our routers. For step-by-step guidance, please refer to the “Teldat Dm 748-I Software Updating” manual. -
Page 36: Establishing A Connection To The Router
Connecting for Configuration Fig. 18: 4.7.1.2 Connecting Via an IP Terminal (WAN Connector) When connecting through an IP terminal, the Regesta Smart PRO will automatically use its default configuration if no prior setup has been done. The default settings are: •... - Page 37 Ethernet cable (RJ45) provided. • Initiate a Telnet session from the IP terminal to the default IP address, 192.168.1.1 (for the Regesta Smart PRO). • No credentials (username/password) are required to access the console under the default configuration.
-
Page 38: Chapter 5 Compliance
+34 91 807 65 65 5.2 Intended Use of the Equipment The Regesta Smart PRO is designed specifically as an industrial router. Using this equipment in a residential setting may result in radio interference. 5.3 EC Declaration of Conformity (Non-Radio Version) English (EN) Teldat S.A. -
Page 39: Ec Declaration Of Conformity (Radio Version)
5.6 National Restrictions In accordance with Article 10 of Directive 2014/53/EU, we advise that there may be national restrictions and authoriz- ation requirements, which are subject to change. Teldat S.A. recommends consulting local authorities for the latest information regarding national regulations. -
Page 40: Appendix A Technical Information
BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.2 WAN Base-T Connector RJ45 WAN RJ45 PIN FE Signals GE Signals BI-DA+ BI-DA+ BI-DA- BI-DA- BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.3 WAN SFP Connector Standard SFP connector Regesta Smart PRO... -
Page 41: Lan Switch Connector
BI-DB+ BI-DB+ BI-DC+ BI-DC- BI-DB- BI-DB- BI-DD+ BI-DD- A.1.5 WWAN/RF Connectors Devices with this interface come with two SMA female connectors. SMA Female Internal RF in/out External A.1.6 Configuration Connector RJ45 CONFIGURATION CONF TxD (input) RxD (output) Regesta Smart PRO... -
Page 42: Rs-232 Serial Port Connectors
2-wire terminal block with 5.08 mm - AC-powered version: pitch Phase and Neutral connectors without assignation. - DC-powered version: V+ and V- connectors with polarity. A.2 Technical Specifications A.2.1 Hardware Architecture MEMORY 128 Mbytes in SDRAM. STORAGE UNIT FLASH Memory (32 Mbytes). Regesta Smart PRO... -
Page 43: Lan Interface
Standard for E1 interface (1.5 KV). A.2.5 WAN SFP Interface STANDARDS 802.1Q (VLAN). 1000-Base-X. MSA and SFF 8472 compliant. SPEED 1000 Mbps full duplex. TYPES LX/LH (single-mode 1310 nm). SX (multi-mode 850 nm). ZX (single-mode 1550 nm). CONNECTOR Standard SFP connector. Regesta Smart PRO... -
Page 44: Wireless Wan Interface
Optional RJ45 female on the connector panel. A.2.9 RS-485 Serial Interface STANDARDS 2-4 wire RS-485/RS-422 configurable via software. Bus termination configurable via software. SPEED From 300 to 115200 bps. CONNECTOR Optional RJ45 female on the connector panel. A.2.10 Power Supply Specifications Regesta Smart PRO... -
Page 45: Dimensions And Weight
LENGTH x WIDTH x HEIGHT 140 x 80 x 190 mm. WEIGHT 1 Kg. A.2.12 Environmental Specifications TEMPERATURE RANGE OPERATION: -20 ºC to +70 ºC STORAGE: -25º to +70 ºC RELATIVE HUMIDITY 5 % to 93 % Regesta Smart PRO... -
Page 46: The Meaning Of S1 And S2 Leds
The serial interface has not been detected/installed, is configured as DOWN, or the Control signal is inactive. The serial interface is detected, the Control signal is active and: Unbalanced mode: the interface awaiting data from the Central site (serial). Regesta Smart PRO... - Page 47 The serial interface has not been detected/installed or is configured as DOWN. The serial interface is detected and the Control signal is inactive. YELLOW The serial interface is testing. GREEN The Control signal is active, the interface is UP. Regesta Smart PRO...
-
Page 48: Rs-485 Driver
(serial). (Non-transparent mode) Flashing: Data is being transferred through the serial interface. (Transparent and non-transparent modes). A.3.2.2 SCADA IEC-101 LED behavior in CENTER mode. The serial interface has not been detected/installed or is configured as DOWN. Regesta Smart PRO... - Page 49 Flashing: Data is being transferred through the serial interface. (For all modes). A.3.2.3 ASDP LED behavior in MASTER and SLAVE modes. The serial interface has not been detected/installed or is configured as DOWN. GREEN Interface is UP. A.3.2.4 ASYNC LED behavior for the ASYNC protocol. Regesta Smart PRO...
- Page 50 Technical Information Teldat S.A. The serial interface has not been detected/installed. The serial interface is detected and configured as DOWN. GREEN Steady: Interface is UP. Flashing: Data is being transferred through the serial interface. Regesta Smart PRO...
-
Page 51: Appendix B Radio Information
Teldat S.A. Appendix B Radio Information B.1 RF WWAN Specifications The Regesta Smart PRO model, equipped with the EC25 module, provides network connectivity across various radio frequency bands, adhering to the latest 3GPP standards, including: • LTE (3GPP Release 10), •... - Page 52 Tx: 824–849 MHz +33 dBm ± 2 dB Rx: 869–894 MHz +27 dBm ± 3 dB (8-PSK) PCS 1900 (1900 MHz) Tx: 1850–1910 MHz +30 dBm ± 2 dB Rx: 1930–1990 MHz +26 dBm ± 3 dB (8-PSK) Regesta Smart PRO...
