Technical Information
A.1.4 LAN Switch Connector
Devices with this interface come with four RJ45 connectors.
RJ45 LAN
A.1.5 WWAN/RF Connectors
Devices with this interface come with two SMA female connectors.
SMA Female
A.1.6 Configuration Connector
RJ45 CONFIGURATION
36
RJ45 PIN
1
2
3
4
5
6
7
8
PIN
Internal
External
PIN
1
2
3
4
5
6
7
8
FE Signals
BI-DA+
BI-DA-
BI-DB+
--
--
BI-DB-
--
--
ANT
RF in/out
GND
CONF
--
TxD (input)
GND
--
--
GND
RxD (output)
--
GE Signals
BI-DA+
BI-DA-
BI-DB+
BI-DC+
BI-DC-
BI-DB-
BI-DD+
BI-DD-
Regesta Smart PRO
Teldat S.A.
