Connector Panel - Teldat Regesta Smart PRO Manual

2 Product Overview
Ethernet WAN in-
WAN
terface (RJ45)
Ethernet WAN in-
SFP
terface (SFP)
Multi standard seri-
S1
al interface 1
Multi standard seri-
S2
al interface 2
Please be aware that the behavior of certain LEDs may vary depending on the device's configuration.

2.4.2 Connector Panel

To access the connector panel, you will need to remove the protective casing covering it. For detailed instructions on
removing or installing the protective cover, please refer to the section titled
tector on page 15.
The figure below illustrates the connector panel, which includes all the connectors available on the Regesta Smart
PRO router.
10
• Steady: No data transfer is occurring.
Green
• Flashing: Data is being transferred.
Off The Ethernet WAN is either disabled or not connected.
Ethernet connection (link) established:
Green
• Steady: No data transfer is occurring.
• Flashing: Data is being transferred.
Off SFP is not used.
Green Ethernet SFP connection (link) is established
Off Serial port 1 is disabled or not initialized.
Green The port is active and shows interface activity:
• Steady: No data transfer is occurring.
• Flashing: Data is being transferred.
(*) This behavior is typical for S1, depending on the driver and
protocol.
For further information, refer to
LEDs on page 41.
Off Serial port 2 is disabled or not initialized.
Green The port is active and shows interface activity:
• Steady: No data transfer is occurring.
• Flashing: Data is being transferred.
(*) This behavior is typical for S2, depending on the driver and
protocol.
For further information, refer to
LEDs on page 41.
The Meaning of S1 and S2
The Meaning of S1 and S2
Removing/Installing the Connector Pro-
