Teldat Router User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Teldat Router
PCMCIA-UMTS Interface
Doc. DM757-I Rev. 10.60
March, 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Router and is the answer not in the manual?

Questions and answers

Related Manuals for Teldat Router

Summary of Contents for Teldat Router

  • Page 1 Teldat Router PCMCIA-UMTS Interface Doc. DM757-I Rev. 10.60 March, 2007...

  • Page 2: Table Of Contents

    INDEX Chapter 1 Introduction .....................1 Description ......................... 2 Chapter 2 Configuration....................4 Introduction ........................5 1.1. Adding a PCMCIA-UMTS device................5 1.2. DIAL Connection Profile..................6 3GPP-ACCESSIBILITY-CONTROL ............... 6 • 3GPP-ACCESSIBILITY-CONTROL PING..........7 • 3GPP-ACCESSIBILITY-CONTOL TRACE..........7 • 3GPP-ACCESSIBILITY-CONTROL TIMER..........7 •...
  • Page 3 GPRS IMSI......................25 GPRS LIST ......................25 GPRS NEIGHBOUR ....................25 GPRS OPERATOR....................26 GPRS QUALITY...................... 26 GPRS SIM-ID......................26 1.6. LIST ........................26 1.7. RESET ........................27 1.8. EXIT ........................27 PCMCIA Monitoring Commands ..................28 2.1. SYSTEM PCMCIA DEBUG.................. 28 2.2.

  • Page 4: Chapter 1 Introduction

    Chapter 1 Introduction...

  • Page 5: Description

    TELDAT ROUTER– UMTS Introduction Doc.DM757-I Rev.10.60...
  • Page 6 Controller) and a series of B Nodes dependent on this. B Nodes are network elements that correspond to the base stations. • Mobile Terminals. UMTS specifications use the term User Equipment (UE). TELDAT ROUTER– UMTS Introduction Doc.DM757-I Rev.10.60 I - 3...

  • Page 7: Chapter 2 Configuration

    Chapter 2 Configuration...

  • Page 8: Introduction

    We have a PCMCIA interface in SLOT 2, over which we are going to insert a UMTS card. We create the umts2/0 interface and indicate that AT commands will be used over it. Config>add device pcmcia umts 2 0 Config>set data-link at umts2/0 TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 5...

  • Page 9: Dial Connection Profile

    As already mentioned, the mechanism the PPP protocol has for point-to-point connection control (Echo-request/Echo-reply) is ineffective in these connections as it is only significant at a “local” level i.e. between the router and the connected module. Various mechanisms have been implemented to verify the connection status. These can be grouped into two types, intrusive (originating data traffic on line and therefore billable) and non-intrusive (does not originate data traffic).

  • Page 10: 3Gpp-Accessibility-Control Ping

    <counter> : represents the limit for the outgoing packets (sent to the network) for the type configured without receiving incoming packets. Once this value has been reached, the link disconnection process activates in order to try a new connection. <type>: Type of monitored outgoing traffic. TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 7...

  • Page 11: B) 3Gpp-Bearer-Service-Type

    To find out the values which permit a determined module or card, enter the commands mode, as explained in the section on monitoring, and enter AT+CBST=?. 1.3. Adding a PPP Interface Add a PPP interface. Example: Config>add device ppp 1 Added PPP interface ppp1 Config> TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 8...

  • Page 12: Ppp Configuration

    Echo functionality is not required (“lcp echo-req off” command). The PPP is only significant locally, i.e. between the router and the connected UMTS module. The echo DOES NOT detect link drops nor loss of signal. Similarly, the extreme remote IP address that appears during negotiation is the module internal IP address, which again makes no sense to have in the routing table.
  • Page 13 PPP config> authentication sent-user MOVISTAR password MOVISTAR ppp1 PPP config> ipcp local address assigned ppp1 PPP config> lcp echo-req off ppp1 PPP config> no ipcp peer-route ppp1 PPP config> ppp1 PPP config>exit ppp1 config> ppp1 config>exit Config> TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 10...

  • Page 14: Configuring The Umts Interface

    Set frame size Set default config Set PIN number for internal Module speed Set speed umts UMTS configuration wait-time Set maximum connection time exit Return to previous menu umts2/0 AT config> TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 11...

  • Page 15: Additional-Control-Command

    Disables the flow control. When this parameter is disabled, there is no flow control available in the interface. By default this parameter is disabled. Syntax: gprs0/0 AT config>disable flow-ctrl-option Example: gprs0/0 AT config>disable flow-ctrl-option gprs0/0 AT config> TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 12...

  • Page 16: Enable

    In PDP context disconnection perform detach frame-size speed umts wait-time umts2/0 AT config> 3.8. PIN Configures the PIN number for the SIM inserted in the module. Example: umts2/0 AT config>pin plain 1235 TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 13...

  • Page 17: Speed

    Note: On listing the interface configuration, the PIN value is displayed in encrypted mode. For the above example: Example: umts2/0 AT config>show conf ; Showing Menu and Submenus Configuration ... ; ATLAS Router 2 8 Version 10.5.1-Alfa pin ciphered 0xFEC7DB8210108C93 3.9. SPEED Permits you to configure the base interface data speed. Example: umts2/0 AT config>speed ?

  • Page 18: Exit

    Example: umts2/0 AT config>wait-time ? <0..65535> Value in the specified range umts2/0 AT config>wait-time 60 3.12. EXIT Returns to the previous menu. Example: umts2/0 AT config>exit Config> TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 15...

  • Page 19: Configuring Ip

    Once the configuration has been carried out and the device restarted, you need to check that the card is operative. PCMCIA cards can be inserted and extracted without having to restart the device when inserting (and extracting) in order to be detected and vice versa, i.e. hot-swap. TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 16...

  • Page 20: Checking The Connection

    PPP.056 ppp1:umts2/0 LCP ProtComp available (0x0702) 12/28/04 11:36:46 PPP.057 ppp1:umts2/0 LCP AddrCtrlComp available (0x0802) 12/28/04 11:36:46 PPP.087 ppp1:umts2/0 LCP Negotiation successful 12/28/04 11:36:46 AT.020 Dialer UMTS command CIR_FLOWCONTROL local st 5 intf umts2/0 TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 17...
  • Page 21 PPP.011 ppp1:umts2/0 Out frame, type 0x0021, size 85 12/28/04 11:36:53 PPP.012 ppp1:umts2/0 In PFC frame, 0x21 [OK] 64 bytes from 216.239.37.99: 12/28/04 11:36:53 PPP.011 ppp1:umts2/0 In frame, type 0x0021, size 85 TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 18...
  • Page 22 ----216.239.37.99 PING Statistics---- 10 packets transmitted, 4 packets received, 60% packet loss round-trip (ms) min/avg/max = 733/837/944 *hide TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 19...

  • Page 23: Configuration Templates

    ; -- ELS Config -- enable trace subsystem AT ALL enable trace subsystem PPP ALL exit protocol ip ; -- Internet protocol user configuration -- address ethernet0/0 172.24.79.12 255.255.0.0 address ppp1 unnumbered TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 20...
  • Page 24 1 default rule 1 local-ip ppp1 rule 1 napt translation classless exit feature dns ; -- DNS resolver user configuration -- server 195.235.113.3 server 195.235.96.90 exit dump-command-errors ; --- end --- TELDAT ROUTER– UMTS Configuration Doc.DM757-I Rev.10.60 II - 21...

  • Page 25: Chapter 3 Monitoring

    Chapter 3 Monitoring...

  • Page 26: Interface Monitoring Commands

    Current rcv rate (bps) Current trx rate (bps) 24000 Current rcv rate (bps) 94000 Current trx rate (bps) 4000 Current rcv rate (bps) 128000 Current trx rate (bps) 4000 Current rcv rate (bps) 166000 TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 23...

  • Page 27: Command

    Syntax: umts2/0 AT+gprs ? ATTACH CELLINFO DETACH IMEI IMSI LIST NEIGHBOUR OPERATOR QUALITY SIM-ID a) GPRS ATTACH Manually carries out an ATTACH, register, to the GPRS or UMTS network. TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 24...

  • Page 28: B) Gprs Cellifo

    PS Only UMTS radio access state: WCDMA PS RSSI when connecting: 10 (-93 dBm) g) GPRS NEIGHBOUR Provides information on the neighbor cells that can serve the module. Not available for UMTS. TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 25...

  • Page 29: H) Gprs Operator

    99 unknown (cannot be measured or has not carried out a call). j) GPRS SIM-ID Displays the SIM card identifier number. Not available for UMTS. 1.6. LIST Permits you to monitor information on the interface status. TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 26...

  • Page 30: Reset

    AT.020 ATCMD-->AT+CMEE=1 intf umts2/0 12/28/04 12:10:00 AT.020 ATCMD-->AT$NWRAT=0,1 intf umts2/0 12/28/04 12:10:02 AT.001 Modem initialized sucessfully intf umts2/0 12/28/04 12:10:04 PPP.001 Interface ppp1 ready 1.8. EXIT Returns to the previous menu. Example: umts2/0 AT+exit TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 27...

  • Page 31: System Pcmcia Debug

    12/28/04 12:26:56 serial_cs: register_serial() at 0xf20003f8,irq 34 slot 2 line 0 success 12/28/04 12:26:56 serial_attach() success on 0x01010810 12/28/04 12:26:56 cdrmngr: do_insert 0 success 12/28/04 12:26:57 uart_speed at 460800 (0x6) TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 28...

  • Page 32: System Pcmcia Dump

    01 99 69 55 1d f6 32 2d a3 60 f8 03 07 50 ff ff 48 c1 05 43 4f 4d 31 00 cftable_entry 0x07 [default] [audio] Vcc Vnom 5V Istatic 15mA Ipeak 850mA Idown 25mA io 0x03f8-0x03ff [lines=3] [8bit] [range] TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 29...
  • Page 33 17 98 a3 60 e8 02 07 50 ff ff 48 c1 05 43 4f 4d 38 00 cftable_entry 0x17 [audio] io 0x02e8-0x02ef [lines=3] [8bit] [range] irq mask 0xffff [pulse] 7 bytes in subtuples TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 30...

  • Page 34: B) System Pcmcia Dump Cis-Reg

    Displays information on how the SLOT PCMCIA controller has been configured. Example: +system pcmcia dump socket-state Identification and revision= *(0x00)=0x84 Chip information = *(0x1f)=0x00 PCMCIA Socket -0/A- Controller Registers ---------------------------------------------- Interface status = *(0x01)=0x7f: [bvd1/stschg] [bvd2/spkr] [detect] [wrprot] [ready] [poweron] TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 31...

  • Page 35: E) System Pcmcia Dump Pci

    Novatel Wireless Merlin UMTS Modem NRM6831 PC Card (0) : serial Novatel Wireless Merlin UMTS Modem U630 PC Card (0) : serial Novatel Wireless Merlin HSDPA Modem U740 PC Card (0) : usb_cb TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 32...
  • Page 36 (1) : usb_cb Option GlobeTrotter GT 3G+ EMEA Cardbus (0) : serial_cb Option GlobeTrotter EDGE CardBus (0) : serial Sierra Wireless AirCard7xx/8xx (0) : serial Sierra Wireless AirCard510 (0) : serial TELDAT ROUTER– UMTS Monitoring Doc.DM757-I Rev.10.60 III - 33...
