Teldat S.A.
Be sure to observe the labeling carefully to avoid confusion with other ports:
WAN and SFP Connectors
Fig. 11:
4.2.2.1 Laser Information
Warning
Laser Radiation. Do not use optical instruments directly or without proper protection. This is a CLASS 1
LASER PRODUCT.
Only class 1 SFP modules compliant with the IEC/EN 60825-1:2007 standard should be installed in the
card socket.

4.2.3 4-Port Ethernet Switch Connections

Certain models of the Regesta Smart PRO router are equipped with a 4-port 10/100/1000 Base-T switch, enabling
automatic MDI/MDIX connection to a local area network (LAN).
Be sure to carefully observe the labeling to avoid confusing this switch with other ports:
Regesta Smart PRO
Ensure that the SFP transceivers you choose comply with the following regula-
tions:
• Class 1
• IEC/EN60825-1:2007 2nd Edition or any later European standard
• FCC 21 CFR Chapter 1, Subchapter J (in accordance with FDA and CDRH re-
quirements)
• 2014/30/EU EMC Directive and the 2014/35/EU Low Voltage Directive for CE
marking
• UL and/or CSA certified components for North American use
• 47 CFR Part 15, Class A
4 Connecting the Router
